P. 7
MS1270
Pitch 12,7 mm
Belt Surface Close
Sidewall No
Approved FDA
Curve No
Cleanability Good
Thickness 8,8 mm
Flight Yes
MS1270 Series Features and Benefits
* Less vibration in high speed and nosebar applications
* High wear resistance at minimum turning radius needed high speed applications
* Long life, easy maintenance
MS 1270 Standart Belt Witdh
mm mm mm mm mm mm
82 85 101 114 153 170
255 304 340 425 510 595
680 765 ... ** Standart belt increments 85 mm
** Inquire for special sizes
Strength Temperature Weight
Belt Material
N/m min °C max °C Kg/m²
Polyproplene 12500 4 101 4,7
Polyethylene 7500 -50 70 6
POM 18300 -40 90 8
***This method generally used for tight transfer with nosebar, deadplate
or with small idling rollers the motor with the drive shaft can be arranged as shown below.
